Non-Intrusive Visual Inspection for Marine Engines and Rotating Equipment
Many critical components of marine engines and industrial machinery can be visually inspected before complete disassembly. Using the PCE-VE 800N4 industrial videoscope with a 4-way articulating probe, MECPARTNER performs high-resolution internal inspections through existing access ports. The 2.8 mm diameter camera allows access to confined areas while capturing high-quality photos and videos for technical assessment and reporting.

Key Advantages

  • Internal inspection without complete dismantling
  • Reduced troubleshooting and diagnostic time
  • Minimized unnecessary disassembly costs
  • Supports predictive and planned maintenance
  • Photo and video documentation
  • Professional technical reporting suitable for owners and classification societies

Applications – Main Engines (2-Stroke & 4-Stroke)

  • Main bearing visual inspection
  • Crankcase internal inspection
  • Connecting rod inspection
  • Crosshead area inspection
  • Cylinder liner surface assessment
  • Piston crown underside inspection
  • Scavenge space inspection
  • Exhaust port inspection
  • Camshaft area inspection (where accessible)

Auxiliary Diesel Engines

  • Main bearings
  • Big-end bearings
  • Cylinder liners
  • Pistons
  • Valve pockets
  • Combustion chamber inspection

Turbochargers

  • Compressor wheel inspection
  • Turbine wheel inspection
  • Housing internal condition
  • Blade damage assessment
  • Foreign Object Damage (FOD) detection
  • Corrosion and crack indication

Other Industrial Applications

  • Gearboxes
  • Reduction gears
  • Pumps
  • Compressors
  • Turbines
  • Internal pipe inspection
  • Weld inspection
  • Confined-space visual inspection

Technical Specifications

  • Equipment: PCE-VE 800N4
  • Camera Diameter: Ø 2.8 mm
  • Probe Length: 1.5 m
  • 4-Way Articulating Probe
  • Integrated LED Illumination
  • Photo & Video Recording
  • 5-inch LCD Display
  • IP58 Waterproof Probe
  • SD Card Data Storage

Inspection Deliverables

  • Visual Inspection Report
  • High-resolution photographs
  • Video recordings
  • Marked defect locations
  • Technical assessment
  • Maintenance and repair recommendations

Typical Inspection Scenarios

  • Pre-inspection of main bearings
  • Crankcase internal condition assessment
  • Pre-honing cylinder liner inspection
  • Piston and piston ring damage evaluation
  • Turbocharger blade condition assessment
  • Pre-purchase engine inspection
  • Initial damage assessment after machinery failure
  • Condition assessment prior to scheduled maintenance
